Excavator:yuchai YC35-8 3.5 ton excavator

Code Item Unit YC35-8

A Max. Digging Height mm 5190

B Max. Dumping Height mm 3670

C Max. Digging Depth mm 3546

D Max. Digging Radius mm 5630

D1 Max. Horizontal Digging Length mm 5486

E Max. Digging Height Radius mm 3265

F Min. Slewing Radius mm 1992

G Max. Depth of Bulldozer mm 460

H Max. Height of Bulldozer mm 210

　 Max. Digging Force kN 22.2

Code Item Unit YC35-8

　 Operating Weight kg 3740

　 Standard Bucket Capacity m³ 0.12

　 Engine 　 Cummins A2300 | KUBOTAV2203

　 Power of Engine kw/rpm 30.5/2200 | 29.2/2200

A Machine Length mm 5250

B Machine Height mm 2470

C Overall Width mm 1518

D Crawler Width mm 300 ( Steel/Rubber )

F Crawler Length mm 2100

G Wheel-Base mm 1620

H Min. Ground Clearance mm 320

I Overall Height mm 1690

J Width of Platform mm 1494

K Height of Engine Hood mm 1385

L Height from Floor to Platform mm 546

　 Width of Bucket mm 608

　 Walking Speed(Low/High) km/h 2.4/4.3

　 Platform Slewing Speed rpm 11.5

　 Cab 　

　 The Deflexion 　

　 The Angle of Deflexion (Left/Right) ° 80/50
